4-port HDMI to UTP splitter

Product Description

Manhattan 4-port HDMI to UTP splitter
Send HDMI signal over UTP this transmitter together with the 185353, the receiving unit, makes it possible. Signals up to 1080P can be sent without any problems over a distance of 50m. You must take the receiver (185353) with it, this is not included and is not included in the price. It is possible to split the signal with this Extending Splitter / Transmitter and send it to four different monitors, for this you must also take 4 receivers (185353) with it.

Specifications

HDMI signal converter (Transmitting Unit) over UTP
Works with separate receivers, our article number 185353
Input Video Signal: 400-600 mV
Input DDC signal: 5 V pp (TTL)
Maximum single-link range: 1.65 Gbps and 1080p resolution
Outgoing video: HDMI 1.3, HDCP 1.4a
4 exits via utp
Frequency: 1.65 Gbps / 165 MHz
Supported resolutions: DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Power supply: 12 VDC / 1 A included
Dimensions: 162 x 100 x 25 mm
Weight: 430 g
